Place of Origin:
China
Brand Name:
WNK
Model Number:
WNK8010
Video
Video
The Submersible Level Sensor is a reliable and accurate hydraulic level transmitter developed by our company. It is suitable for the measurement of various liquid levels in the fields of oil and gas, chemical, water treatment, power, metallurgy, etc. It has a wide range of temperature adaptation, overload protection, and stability, making it a popular choice for industrial applications.
The Submersible Level Sensor has a temperature range of -20℃ to +80℃, and can withstand overload of up to 150% of the sensor range. It offers excellent stability with an accuracy of 0.25%FS/year. It also has a variety of output options, including 4~20mA, 0-10mA, 0-5V, 1-5V, and customization.
The Submersible Level Sensor is a reliable and versatile tool for precise level measurement in any applications. Our Level Transmitter/Water Level Sensor is designed to provide accurate and reliable readings for any liquid levels and provides the highest level of protection against corrosion.
| Parameter | Value |
|---|---|
| Housing material | Stainless Steel |
| Product Name | Submersible Level Transmitter/water Level Sensor |
| Output | 4~20mA, 0-10mA, 0-5V, 1-5V, Customization |
| Overload | 150% Of Sensor Range |
| Power Supply | 24VDC |
| Temperature Range | -20℃~+80℃ |
| Application | For Tank, Pool,river, Underwater Etc Open Vessel Measurement |
| Protection class | IP68 |
| Cable material | Polyvinyl Fluoride, PTFE |
| Stability | 0.25%FS/ Year |
The WNK8010 Submersible Level Sensor is a reliable and accurate water level sensor from WNK. It is designed to measure liquid levels in submerged containers and tanks with a temperature range of -20℃ to +80℃. It is made of durable stainless steel with an IP68 protection class, making it suitable for harsh and wet environments. Its output can be customized from 4~20mA, 0-10mA, 0-5V, and 1-5V, providing a flexible solution for different needs. This Submersible Level Transmitter is ideal for applications such as water treatment, groundwater monitoring, and hydrologic forecasting. It is widely used for water level sensor applications in a variety of industries such as agriculture, industrial, and commercial. This sensor is perfect for monitoring liquid levels in wells, streams, lakes, and other bodies of water for hydrological studies. With its high accuracy and reliable performance, this WNK8010 Submersible Level Sensor is a great choice for accurate and reliable water monitoring.
We provide technical support and service for all our Submersible Level Sensors. Our team of experienced technicians is available for any questions or advice you might need. Whether you are having trouble with installation, troubleshooting, or you just need some tips to get the most out of your sensor, our team is here to help!
We provide support in the following areas:
For any questions or advice you need, please contact us through our website or email.
The Submersible Level Sensor is packaged in a sealed corrugated box. The box is filled with foam-in-place material to cushion the Sensor during shipping. A custom foam insert is included to secure the Sensor and protect it during transit.
The box is sealed with heavy-duty packing tape and labeled with the shipment's destination.
The Submersible Level Sensor is shipped via courier with tracking information provided.
