Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer

Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer

ExiaII CT4 Miniature Pressure Sensors

1 Year Warranty Smart Pressure Transducer

1 Year Warranty Miniature Pressure Sensors

Place of Origin:

Anhui, China

Brand Name:

WNK

Certification:

CE, ROHS

Model Number:

WNK80mA

Contact Us
Request A Quote
Product Details
Warranty:
1 YEAR
Customized Support:
OEM, ODM
Measured Media:
Liquid, Gas And Steam
Output Signals:
4~20mA, 1-5V, 0-10V, 0.5V-4.5V, I2C
Accuracy:
0.2%F.S, 0.5%F.S
Pressure Range:
0-300KPa~10MPa
Protection Class:
IP65
Ex-proof:
ExiaII CT4/CT6, ExidIICT6
Housing Material:
304SST
Power Supply:
24VDC/12VDC/5VDC/3.3V
Electrical Connection:
Packard, M12, DIN43650, Cable
Keywords:
Pressure Transmitter/Pressure Transducer
Port:
Shanghai Port
Highlight:

ExiaII CT4 Miniature Pressure Sensors

,

1 Year Warranty Smart Pressure Transducer

,

1 Year Warranty Miniature Pressure Sensors

Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
$10.00 - $35.00/Pieces
Packaging Details
each product in one inner paper box with protection
Delivery Time
5-8 work days
Payment Terms
T/T, Western Union, MoneyGram, Paypal
Supply Ability
2000 Set/Sets per Week Pressure Transducer
Product Description

4-20mA Smart Water Pressure Sensor/Pressure Transmitter/Pressure Transducer



WNK80MA Gauge/Absolute/Sealing Pressure Transmitter
Applicable media
Liquid, Gas
Pressure range
0-60bar
Pressure measurment
Gauge Pressure, Absolute pressure, Sealing pressure
Output
4-20mA/0.5-4.5V/1 -5V/0-10V/I2C
Accuracy(linearity,Hysteresis and Repeatability)
0.5%F.S.(Typical)
Power supply
24VDC/12VDC/5VDC/3.3V
Compensation temperature
-20~85ºC
Ambient temperature
-40~125ºC
Working temperature
-40~125ºC
Temperature drift(zero)
±0.15% F.S. (-20~85ºC)
Temperature drift(full range)
±0.15% F.S. (-20~85ºC)
power(electrical) connect
Parkard, M12,  DIN43650, Cable outlet
Mechanical connection
G1/4, 1/4NPT, 1/8NPT,  M12*1.5, customize
Housing material
304 stainless steel(inner core is 316 stainless steel)
Protection
IP65



>>> Applications
- Automobile, Compressor and Refrigeration Industry
- Engineering machinery
- Pressure control and monitor
 - Water treatment system
- Hydraulic and Pneumatics
- HAVC and BAS Control
- Pump, fitness equipment, household appliances
- Factory Automation
- Fluid Control and Instrumentation Systems












Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 1

Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 3

Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 5

Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 7

Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 9

Product Show

Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 11Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 13Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 15Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 17



 Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 19





 ,Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 21









Company Information

 Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 23

Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 25



Exhibition

 Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 27



Certification

 Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 29





Packaging & Shipping

 Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 31

Exiaii Ct4 Miniature Pressure Sensors /Smart Pressure Transducer 33

FAQ

 Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
