Name: ODM 0.5-4.5V Submersible Pump Water Level Sensor 150% Times Overload
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK8010-T
Price: Negotiable USD
Availability: InStock

Home > products > Water Level Transmitter >

ODM 0.5-4.5V Submersible Pump Water Level Sensor 150% Times Overload

4.5V submersible pump water level sensor

ODM Submersible Pump Water Level Sensor

150% Times submersible water pressure sensor

Place of Origin:

Anhui, China

Brand Name:

WNK

Model Number:

WNK8010-T

Request A Quote

ODM 0.5-4.5V Submersible Pump Water Level Sensor 150% Times Overload

Product Details

Warranty:

1 YEAR

Customized Support:

OEM, ODM

Product Name:

Factory Supply 4-20mA 0.5-4.5V Submersible Liquid Level Sensor

Accuracy:

±0.25% FS/year, ±0.5% FS/year

Level Range:

0-200m H2O

Power Supply:

24V/12V/5V/3.3V

Output:

4-20mA, 1-5V, 0.5-4.5, 0-5V, 0-10V, IIC,HART,RS485

Housing Material:

Stainless Steel

Cable Length:

Protection Class:

IP68

Cable Material:

PE/PF

Overload:

150% Times

Port:

Shanghai, Shenzhen

Highlight:

4.5V submersible pump water level sensor

ODM Submersible Pump Water Level Sensor

150% Times submersible water pressure sensor

Payment & Shipping Terms

Minimum Order Quantity

1pcs

Price

$55.00 - $70.00/Pieces

Packaging Details

Paper carton or as client's requirement

Delivery Time

5-8 work days

Payment Terms

T/T, Western Union, MoneyGram, Paypal

Supply Ability

100000 Piece/Pieces per Month

4-20mA 0.5-4.5V RS485 Submersible Water Level Sensor Transmitter for Agricultural Irrigation

Get Best Price

Video

Comprehensive Probe style Water Level Sensor (Submersible) for Diverse Applications

Get Best Price

Video

Submersible Water Level Sensor with 0-1~200 MH2O Range and 12-36V Power Supply

Get Best Price

Video

Submersible Probe Water Level Transmitter With 0.25%FS Stability (IP68

Get Best Price

86-551-65369655

Contact Now

Product Description

Factory Supply 4-20mA 0.5-4.5V Submersible Liquid Level Sensor

- Our WNK8010 liquid leve sensor with high performance diffused silicon piezoresistive pressure sensor as the measuring element,
- With the reliable amplified circuit and precision temperature compensation, to transfer the gauge or absolute pressure of measurement medium to standard voltage or current signal.
- This product comes with compact profile, easy to install, it can measure the level height directly when through into the liquor.

Applications

• Water tank level measurement and control.
• Fuel tank level measurement and monitor (diesel, gasoline, kerosene and so on).
• Liquid level measuring in tank, rivers, lake, sea, well, tube, underground water and so on.
• Special occasion such as high temperature liquid (up to 100 degree C), strongly corrosion liquid level measurement (request by customized.)

Features

• Adopting diffusion silicon oil-filled sensor
• Max measure range up to 200 meters or more
• High Stability, provide 0.1, 0.2, 0.5 accuracy for option
• Factory direct price

Pressure measurment	Liquid,Water
Accuracy	±0.2% FS/year, ±0.5% FS/year
Output	4~20mA, 0-5V ,0.5-4.5V ,I2C
Power supply	24VDC
Ambient/Process/Compensation temperature	-20~80℃
Housing material	Stainless steel
Ingress Protection	IP68
Measured Range	0-0.5~200mH2O
Display	Available
Max Overload	150% of sensor range
Burst Pressure	300% of sensor range
Measure Medium	Liquid
Stability	0.25%FS/ year
Cable material	Polyvinyl Fluoride, PTFE

Our Company

Packing&Shipping

FAQ

Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.
Large orders are recommended to ship by sea
