316SS Flush High Temperature Pressure Transmitter With Heat Sinks

316SS Flush High Temperature Pressure Transmitter With Heat Sinks

Flush High Temperature Pressure Transmitter

Heat Sinks High Temperature Pressure Transmitter

316SS flush pressure transmitter

Place of Origin:

Anhui, China

Brand Name:

WNK

Model Number:

WNK805

Contact Us
Request A Quote
Product Details
Warranty:
1 Year
Customized Support:
OEM, ODM
Accuracy:
0.5% FS, 0.5% FS
Output Signal:
4~20mA, 1-5V
Pressure Range:
-100Kpa ~ 60 MPa
Operating Temperature:
-20~85 ℃
Power Supply:
10.5-55V DC, 10.5-30V DC
Housing Material:
304/316SS
Measured Media:
Liquid, Gas, Steam
Ex-proof:
ExiaII CT4/CT6, ExidIICT6
Type:
Diffused Silicon Pressure Transmitter
Keywords:
Flush Pressure Sensor/ High Temperature Pressure Sensor
Port:
Shanghai/Ningbo
Highlight:

Flush High Temperature Pressure Transmitter

,

Heat Sinks High Temperature Pressure Transmitter

,

316SS flush pressure transmitter

Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
$45.00 - $65.00/Pieces
Packaging Details
Each piece into individual carton with foam protection
Or as per client's request
Delivery Time
5-8 work days
Payment Terms
T/T, Western Union, MoneyGram, Paypal
Supply Ability
2000 Piece/Pieces per Month High Temperature Pressure Sensor
Product Description

4-20ma 1-5v Customized High Temperature Flush Pressure Sensor with Heat Sinks

Specifications

 WNK805 Gauge/Absolute Pressure Transmitter

WNK805 integral pressure transmitter adopts stainless steel shell structure, built in stainless steel oil filled sensor, intelligent digital circuit with precise temperature characteristic compensation, it can be used reliably and stably



 Product Features

1.High performance piezoresistive silicon pressure sensor
2.Optional 4~20mA, 0~5V, 1~5V, 0~10V outputs
3.OEM, ODM & customization available
4.Stainless steel 316L housing
5.Intrinsic safety and explosion-proof certificates
6.High protection: IP65
7.Suitable for air, steam, water and fuel oil application
8.ISO9001(2015) certificate
Technical Data



2-Wire Signal Output hydraulic pressure regulator with lcd display
Applicable media
Liquid, Gas, Steam
Pressure measurment
Gauge Pressure, Absolute pressure, Negative pressure, Sealing pressure
Pressure range
0-0.2~-100kPa, 0-0.2~1000kpa, 60mPa
Output signals
4~20mA, 1-5V for optional
Accuracy
0.2, 0.5
Stability
±0.25% FS/year
Zero drift
50% of full range span.
Max overload
200% of sensor range
Display
LED (Optional)
Housing material
304 stainless steel
Mechanical connection
M20×1.5; 1/2-18NPT, 1/4NPT, Customize

Power supply
Non-explosion: 10.5~45V DC
EEX ia:10.5~30 V DC
Ambient temperature
-40~125℃
Process temperature
-40~125℃



Product Show

 316SS Flush High Temperature Pressure Transmitter With Heat Sinks 0316SS Flush High Temperature Pressure Transmitter With Heat Sinks 2316SS Flush High Temperature Pressure Transmitter With Heat Sinks 4316SS Flush High Temperature Pressure Transmitter With Heat Sinks 6316SS Flush High Temperature Pressure Transmitter With Heat Sinks 8316SS Flush High Temperature Pressure Transmitter With Heat Sinks 10

Hot Product



316SS Flush High Temperature Pressure Transmitter With Heat Sinks 12





Company Information



 316SS Flush High Temperature Pressure Transmitter With Heat Sinks 14



Exhibition

 316SS Flush High Temperature Pressure Transmitter With Heat Sinks 16







Certification

 316SS Flush High Temperature Pressure Transmitter With Heat Sinks 18



316SS Flush High Temperature Pressure Transmitter With Heat Sinks 20







316SS Flush High Temperature Pressure Transmitter With Heat Sinks 22




FAQ

 Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea.
