Home > products > Electronic Water Pressure Sensor >
12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction

12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction

12VDC water pressure sensors

0.5% Accuracy water pressure sensors

Place of Origin:

Anhui, China

Brand Name:

WNK

Certification:

CE, ROHS

Model Number:

WNK81mA-g

Contact Us
Request A Quote
12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction
12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction
Product Details
Warranty:
1 Year
Customized Support:
OEM, ODM
Accuracy:
0.5% , 1.0% FS
Output Signal:
4- 20mA, 0.5-4.5V, 0-5V, 1-5V, I2c, Other
Operating Temperature:
-40~85 ℃
Pressure Range:
-100KPA-60MPA
Power Supply:
24VDC 12VDC 5VDC 8-30VDC
Material:
304 SS, 316L
Media:
Water, Liquid, Gas, Steam, Oil, Lubricant
IP Rating:
IP65, IP67
Type:
Gauge, Absolute, Seal, Vacuum
Port:
Shanghai/Ningbo/Shenzhen/Guangzhou
Highlight:

12VDC water pressure sensors

,

0.5% Accuracy water pressure sensors

Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
$20.00 - $28.00/Pieces
Packaging Details
Each piece into individual carton with foam protection
Or as per client's request;
Diffused Silicon Pressure Sensor Transducer Used In Water Hydraulic Systems
Delivery Time
5-8 work days
Payment Terms
T/T, Western Union, MoneyGram, Paypal
Supply Ability
30000 Piece/Pieces per Month Pressure Sensor Transducer
RELATED PRODUCTS
Good price 1%FS Brass Pressure Sensor For Water Parkard Electrical Connection online Video

1%FS Brass Pressure Sensor For Water Parkard Electrical Connection

Get Best Price
Good price 0.5-4.5V Output Brass Pressure Sensor For Air Water HVAC Application online Video

0.5-4.5V Output Brass Pressure Sensor For Air Water HVAC Application

Get Best Price
Good price Anti Corrosive Underwater Pressure Sensor Brass Cable outlet online Video

Anti Corrosive Underwater Pressure Sensor Brass Cable outlet

Get Best Price
Good price 0.5V 4.5V Brass Ceramic Capacitive Pressure Sensor For Liquid Gas online Video

0.5V 4.5V Brass Ceramic Capacitive Pressure Sensor For Liquid Gas

Get Best Price
Contact Us
86-551-65369655
Contact Now
Product Description
Pressure Sensor Pressure Transducer

Pressure sensor is mainly used to complete the closed-loop control of force in hydraulic system. When the control spool suddenly moves, in a very short time will form several times the system operating pressure peak pressure. In typical walking machinery and industrial hydraulics, any pressure sensor can be quickly destroyed if such extreme conditions are not considered in the design.It is necessary to use impact resistant pressure sensor. There are two main methods for pressure sensor to achieve impact resistance. One is strain exchange type chip, the other is external coils.In addition, there is another reason that the pressure sensor is also subjected to continuous pressure pulsation from the hydraulic pump.

WNK81mA Pressure sensor is mainly used in water supply pipeline, gas supply pipeline measurement, hydraulic system measurement, such as booster cylinder, supercharger, gas-liquid booster cylinder, gas-liquid supercharger, pressure machine, compressor, air conditioning and refrigeration equipment and other fields.

12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 0
12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 2

Product Name
0.5-4.5V 4-20mA Low Cost I2C Pressure Sensor For Water Liquid Gas Steam



Pressure Type
Gauge pressure, sealing pressure, absolute pressure



Measure Range
 0-20kPa~60MPa



Output
0.5-4.5v, 4-20mA, I2C, 0-5V, 0-10V, customize



Accuracy
0.5%FS, 1%FS



Compensation Temperature
-20…70℃



Ingress
IP65/IP67



Working Temperature
-45 to 85℃,



Electrical Connection
Packard, M12*1, Cable outlet, Mini DIN43650, Customize



Process Connection
G1/4, 1/4NPT, 1/8NPT, M12*1.5, Customize



12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 5
Company Profile
12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 7
12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 9
12VDC Water Pressure Sensors 0.5% Accuracy cable outlet connction 11
FAQ
Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient
pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.
Large orders are recommended to ship by sea
